Cassia DL-100

The Cassia DL-100 LED Spot Film Viewer features a modern, stylish and simple design. An optimized right side control panel makes this illuminator easy to control. The Cassia DL-100’s pure White LED Light and Multi-channel brightness controller provides cool operation for easy viewing of 5.0 Density Films. A Universal power supply is included with the Cassia DL-100 Film Illuminator.

  • Easily views 5.0 Density Films
  • Pure White LED Light
  • 50,000 hour lamp life
  • Cool Operation
  • Modern, stylish and simple design
  • Multi-channel brightness controller
  • Easy to control – optimized right side control panel
  • Universal power supply
Features
Dimmer Control
Yes
Footswitch
Yes
10 Point Calibration
Yes
Cool Operation
Yes
Specifications
Viewing Window
16″ x 4″ / 4 – 100 mm
Maximum Intensity (Luminance)
1,100,000 cd/m²
Dimmer Control
0 – 100% continuous
Maximum Density
5.0 D
Lamp Life
50,000 hours
Color Temperature
6,000K
Surface Temperature
< 18°C
Power Requirements
85 – 264 VAC / 47 – 60 Hz
Rated Power
200W
Size
15.8″ x 11″ x 10″ / 400 x 280 x 255 mm
Weight
17.2 lbs. / 7.8 kg
Warranty
5 year parts, 1 year labor
