Cassia DL-2010P LED Industrial Illuminator is a unique film viewer that combines a full 8.7″ x 3.2″ / 22 x 8cm viewing area with a 2.4″ x 2.4″ / 6x6cm brite spot for easy viewing of 5.0 density radiographic film.
Features:
- Optimized right-side control panel design
- Multi channel precise brightness controller
- High stability power supply
- Magnetic film holder allows movement
- built in desktop stand
Features | |
---|---|
Dimmer Control | ![]() |
Cool Operation | ![]() |
Low Power Consumption | ![]() |
Long Bulb Life | ![]() |
Specifications | |
---|---|
Maximum Intensity (Luminance) | 180,000 & 1,000,000 cd/m² |
Maximum Density | 4.3 D & 5.0 D |
Viewing Window | 8.7″ x 3.2″ / 22cm x 8cm combined with 2.4″ x 2.4″ / 6cm x 6cm Brite Spot |
Uniformity | 98% Full Screen |
Lamp Life | 50,000 Hour |
Color Temperature | 6,000K |
Surface Temperature | <65°F / 18°C |
Control Mode | Manual + Foot-Switch |
Dimmer Control | 0% to 100% continuous |
Power Requirements | 85-264VAC / 47-60Hz |
Rated Power | 200W |
Weight | 20.3lb / 9.2kg |
Warranty | 5 Years |
