NDT 87-C1

Made In The USA

NDT’s Model 87-C1 Spot Film Viewer is an industrial radiographic film viewer with high intensity output.

Constructed from electro-galvanized steel and painted with a durable polyurethane enamel, this is a truly portable unit. It’s variable dimmer gives precise control of the light source for film interpretation.

  • Fan cooled for prolonged operation
  • Convenient carrying handle
  • Face plate will accept optional iris diaphragm
  • Convenient cord wrap for transport and storage ease
Specifications
Maximum Intensity (Luminance)
50,000 cd/m2
Maximum Density
3.7 D
Dimmer Control
Yes
Viewing Window
5.25″ x 4.75″ glass view screen
Lamps
300 watt BAH photoflood bulb
Maximum Density
3.7 D
Housing
electro-galvanized steel and painted with a durable polyurethane enamel
Footswitch
Optional
Power Requirements
115 VAC, 50 – 60Hz
Size
6″ x 11″ x 11″ (152 x 279 x 279 mm)
Weight
10 lbs / 4.5 kg

87-C1 Foot Switch with cable and plug

87-C1 Accessory Foot Switch

87-C1 Iris Diaphragm – 4″ (102mm) round adjustable opening for high spot masking.

87-C1 Iris Diaphram 4 inch

Accessory Iris for the NDT  87-C1 & 65-C1 viewers

Accessories

NDT 87-C1
87-C1 Footswitch
87-C1 Iris
