NDT DM3011 Densitometer

The NDT DM3011 Densitometer measures up to 5.0 D. Calibration Traceable to NIST. The unique calibration software allows precise user calibration to a certified step wedge.

Includes:

  • DM3011 Series Black – White Densitometer
  • Standard Step Density Tablet
  • Software CD for Auto Calibration
  • Serial Port Cable
  • Power Line
  • Software CD for Auto Calibration
  • Quality Certification
Specifications
Density Range
0.00 – 5.00 D
Aperture
2mm Diameter
Repeatability
±0.01 D
Measuring Error
0.00 – 2.00 ±0.02D
2.00 – 4.50 ±0.05D
4.50 – 5.00 ±0.08D
Power Requirements
50 – 60Hz, 110V or 220V ±10%
Power Dissipation
25 W
Display Type
Three Digital Display
Sampling Time
0.8 seconds
Communication Port
RS232 Port
Software
DM CAL PC Software
Working Temperature:
32°F – 104°F, 0°C – 40°C
Environment
Relative humidity ≤ 85%
Size
9.6″ x 10.6″ x 4.4″ / 260mm x 265mm x 110mm
Weight
4.6 lbs / 2.1 kg
